| GENERAL |
| Type: | Military HF transceiver |
| Frequency range: | 2-15 MHz |
| Tuning steps: | 100 Hz, 1 / 10 / 100 KHz, 1 MHz |
| Frequency stability: | ±100 Hz @ -30 to +55°C (-22 to +131°F) |
| Mode: | AM / SSB / CW |
| Channels / memory management: | |
| Duplex shift / offset: | |
| Power supply: | 12 VDC (NiCd or Lead acid battery pack)
or 11-15 VDC external (3-pin jack) |
| Current drain / power consumption: | RX: 170-200 mA
TX: Max 4 A |
| Antenna impedance / connector: | - / Threads (For whip antenna)
50 ohm ohm / BNC |
| Dimensions (W*H*D): | 290*117*348 mm (11.42*4.6*13.7") |
| Weight: | 7.3 Kg (16.1 lb), with NiCd batteries |
| Other features: |
Clarifier ±50 Hz. Built-in antenna tuner.
Waterproof and submersible.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 16 MHz
|
| Sensitivity: | 0.5 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | 2.4 KHz (-6 dB)
5 KHz (-60 dB) |
| Image rejection: | 90 dB |
| AF output power / speaker: | 1 W at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Low |
|---|
| AM (Carrier): | 6 W | ? W |
| SSB (PEP): | 25 W | 6 W |
| CW: | 10 W | ? W |
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / Two 6-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 198x-200x (Discontinued) |
| Additional info: |
New price 1999 in the US: $3990.00 (Export version)
|
| Related documents: |
User/service manual (18.9 MB)
|
| Modifications and fixes: | |
| Reviews: | Popular Communications: June 1986, page 24 |
| Options / Accessories: |
KC-SP-1
MP-25-AD
MP-25-AW
MP-25-BP
MP-25-CB
MP-25-CH
MP-25-CW
MP-25-HG
MP-25-HP1
MP-25-HS
MP-25-MB
MP-25-MC
MP-25-MW1
MP-25-PSC
MP-25-VS
PN980013
PN980014
|
Solar power unit
Dipole antenna
Folding whip antenna
Rechargeable battery pack. 12 V. NiCd or Pb
Carrying bag
Battery charger. Up to 4 NiCd or Pb packs.
Morse key
Hand generator
Headphones. Military type H140/BU
Handset. Military type H189/GR
Mobile mounting bracket
Hand microphone. Type M-80/U
Mobile whip antenna with ball mount. 2.5 m (9 ft)
Power supply/charger. 110/220 VAC
Voice encryption/scrambler module
Extender board kit
Mobile DC power lead
|
|
