| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 75-88 / 450-512 MHz |
| Tuning steps: | Channelized |
| Frequency stability: | ?% |
| Mode: | FM |
| Channels / memory management: |
16 regular (8 VHF + 8 UHF)
XTAL controlled
1 second switchable scan resume delay
|
| Power supply: | Mains: 220 VAC
or 13.8 VDC |
| Current drain / power consumption: | ? mA @ 13.8 VDC |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola)
or built-in retractable telescopic whip |
| Dimensions (W*H*D): | 200*76*207 mm (7.87*3*8.15") |
| Weight: | 1.72 Kg (3.79 lb) |
| Other features: | Dimmer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz - Ceramic filter: Murata CFM455D
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 20 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 4 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Additional info: | |
| Related documents: |
FM-IF amplifier: TA7060P
FM-IF amplifier: TA7061AP
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
