| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: | 77.1325-88.4250 / 161.100-172.825 MHz |
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
20 regular (10 hi-band + 10 low-band)
RAM storage with battery backup (Two LR-44)
|
| Power supply: | 12-14 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Less than 550 mA |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 164*56*193 mm (6.46*2.2*7.6") |
| Weight: | 1.3 Kg (2.87 lb) |
| Other features: | Binary programming. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 1 uV (20 dB S/N) |
| Squelch sensitivity: | Better than 0.3 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 27 KHz (-6 dB)
40 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | 500 mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Additional info: |
Main PCB: 9-311-017 by ?
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
