| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
Europe
68-88 / 144-174 / 430-512 MHz
|
| Tuning steps: | VHF: 5 KHz
UHF: 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
16 regular @ 10 channels per second
1 monitor
1 search pair
Switchable 2 second scan resume delay
RAM storage with 9 V battery backup
|
| Power supply: | Mains: 220-240 VAC (Fixed power cord)
or 12-15 VDC (Male 2-pin jack) |
| Current drain / power consumption: | Less than 1.5 A @ 12 VDC |
| Antenna impedance / connector: | 50-75 ohm / Two DIN41585 (Motorola) |
| Dimensions (W*H*D): | 276*86*259 mm (10.88*3.38*10.2") |
| Weight: | 3.7 Kg (8.16 lb) |
| Other features: | Tape out jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
VHF: 0.5 uV (20 dB S/N)
UHF: 1 uV (20 dB S/N)
|
| Squelch sensitivity: | Less than 0.5 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 18 KHz (-6 dB)
34 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | 1/4" jack |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By GRE), 197x-198x (Discontinued) |
| Additional info: |
The 20-9115A version is slightly improved with fever birdies.
Also sold in Sweden as Handic 0016
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
