| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
USA
30-50 / 108-136 / 138-174 / 410-512 MHz
|
| Tuning steps: | 5 KHz (VHF low/high)
12.5 KHz (UHF)
25 KHz (Airband) |
| Frequency stability: | ?% |
| Mode: | AM / FM |
| Channels / memory management: |
50 regular in 5 banks @ 3 or 6 channels per second
1 search limit pair
1 priority (3 seconds sampling rate)
3 seconds scan resume delay (Squelch controlled)
RAM storage with a 9 V battery backup
|
| Power supply: | Mains: 120 VAC (Fixed power cord)
or 12-15 VDC (Male 2-pin jack) |
| Current drain / power consumption: | Max 19 W @ 120 VAC
Less than 725 mA @ 13.8 VDC |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola)
or detachable telescopic whip |
| Dimensions (W*H*D): | 260*80*270 mm (10.25*3.15*10.63") |
| Weight: | 3.5 Kg (7.7 lb) |
| Other features: | Tape out jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM (10 dB S/N)
108-136 MHz: 1 uV
FM (20 dB S/N)
30-50 MHz: 0.5 uV
138-174 MHz: 0.5 uV
410-512 MHz: 1 uV
|
| Squelch sensitivity: | Less than 1 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 18 KHz (-6 dB)
30 KHz (-50 dB) |
| Image rejection: | 10.7 MHz: 80 db @ 154 MHz |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | TS 1/4" jack |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, (By GRE), 1980-198x (Discontinued) |
| Additional info: |
FCC ID: AXS9ZAO20-116 (Early) and AAO9ZA20-116 (Later)
New price 1981 in the US: $399.95
New price 1982 in the US: $399.95
New price 1983 in the US: $399.95
|
| Related documents: |
User manual (912 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
