| Type: | SWR / Power meter |
| Frequency range: | 3.5-150 MHz |
| Power measure ranges: | 15 W
150 W |
| Insertion loss: | |
| Impedance / connectors: | 50 ohm / Two SO-239 |
| Power supply: | 12-14 VDC (Fixed power cord), for backlight only |
| Current drain/power consumption: | ? mA |
| Dimensions (W*H*D): | 71*78*100 mm (2.79*3.07*3.94") |
| Weight: | ? g (? lb) |
| Manufactured: | Japan, 20xx-20xx (Discontinued) |
| Additional info: |
Accuracy: ±15% of full scale
Minimun power for accurate SWR measurement is 3 W
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
