| GENERAL |
| Type: | Military HF transceiver |
| Frequency range: | 2-30 MHz |
| Tuning steps: | 100 Hz (TRC300-4 only), 1 / 10 / 100 KHz, 1 / 10 MHz |
| Frequency stability: | 1 ppm @ -15 to +55°C (5 to 131°F) |
| Mode: | AM / SSB / CW |
| Channels / memory management: |
8 presets (TRC300-3 only)
|
| Duplex shift / offset: | No |
| Power supply: | 14.4 VDC |
| Current drain / power consumption: | RX: Less than 200 mA
TX: Max 3.8 A |
| Antenna impedance / connector: | - / Threads (For whip antenna)
50 ohm / BNC |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
AM: 5 uV (12 dB S+N/N)
SSB: 0.8 uV (12 dB S+N/N)
|
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 10 mW at 10% distortion / 300 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 20 W (PEP)
Low: 6 W (PEP)
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | France, 1975-1980 (Discontinued) |
| Additional info: |
The 300 series consist of 300-2, 300-3 and 300-4, with
some slight difference between them.
France also exported this transceiver. Some of them to
South America with a front panel in spanish.
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
TRC-310
|
Linear amplifier, 100 W
|
|
