| GENERAL |
| Type: | Military VHF receiver |
| Frequency range: |
100-124 MHz
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | |
| Mode: | AM / CW |
| Channels / memory management: | |
| Power supply: | Mains: 190-250 VAC
or 6 VDC (Dynamotor supply) |
| Current drain / power consumption: | ? |
| Antenna impedance / connector: | ? ohm / ? |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 12 MHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | 70 dB |
| AF output power / speaker: | 250 mW at ?% distortion / 200 to 2000 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | UK, 1941-194x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
