| GENERAL |
| Type: | Military HF transmitter |
| Frequency range: | 5.3-7 MHz |
| Tuning steps: | Analog / continuous |
| Frequency stability: | Max ? ppm |
| Mode: | AM / CW |
| Channels / memory management: | None |
| Power supply: | 24-28 VDC (Dynamotor supply) |
| Current drain / power consumption: | ? A |
| Antenna impedance / connector: | ? ohm / ? |
| Dimensions (W*H*D): | 184*223*382 mm (7.24*8.78*15.04") |
| Weight: | 6.8 Kg (15 lb) |
| Other features: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
~40 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA (By Western Electric), 1940-194x (Discontinued) |
| Additional info: |
This transmitter was part of the SCR-274-N command set.
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
