| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
150-170 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
8 regular
1 priority
One XTAL per channel (HC-25U)
|
| Power supply: | Mains: 117 VAC (Male 2-pin jack)
or 12 VDC (3-pin DIN jack) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (20 dB QS) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 1.5 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1972-197x (Discontinued) |
| Additional info: |
New price 1972 in the US: $179.95
|
| Related documents: | User manual (1.4 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
