| GENERAL |
| Type: | Marine HF transceiver |
| Frequency range: |
TX: 27.680-27.980 MHz
RX: 27.680-27.980 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±0.001% @ -20 to +50°C (-4 to +122°F) |
| Mode: | AM / SSB |
| Channels / memory management: | 10 |
| Duplex shift / offset: | No |
| Power supply: | 11.7-15.9 VDC (Male 3-pin jack) |
| Current drain / power consumption: | RX: Max 600 mA
TX: Max 2.2 A |
| Antenna impedance / connector: | 52 ohm / SO-239 |
| Dimensions (W*H*D): | 185*58*231 mm (7.28*2.28*9.1") |
| Weight: | 1.52 Kg (3.3 lb) |
| Other features: | PA. Channel 88 button. ANL/NB. Dual watch. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 10.695 MHz
|
| Sensitivity: |
AM: 0.5 uV (10 dB S+N/N)
SSB: 0.25 uV (10 dB S+N/N)
|
| Squelch sensitivity: | Less than 0.5 uV (Threshold) |
| Selectivity: | 4.2 KHz (-6 dB)
7 KHz (-60 dB) |
| Image rejection: | 75 dB |
| AF output power / speaker: | 3 W at 10% distortion / 16 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
AM: 4 W
SSB: 12 W (PEP)
|
| Modulation system: |
AM: High and low level
SSB: Balanced
|
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Taiwan, 1986-198x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (2.7 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
