| GENERAL |
| Type: | License-free "902-928 MHz USA" transceiver |
| Frequency range: | 906.275-923.750 MHz |
| Channels / tuning steps: | Channelized (25 KHz raster) |
| Frequency stability: | ? ppm |
| Mode: | FM with FHSS (400 ms hop rate, 50 frequencies per channel from a pool of 700) |
| Memory channels / management: |
1000 "talk channels" (Hop sets)
|
| Repeater shift / offset: | Simplex only |
| Power supply: | 4.5-4.8 VDC (NiMH battery pack or three LR6 / AA alkaline batteries) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | Non-removable antenna |
| Dimensions (W*H*D): | 57*132*39 mm (2.24*5.2*1.54") |
| Weight: | 91 g (3.2 oz), without batteries |
| Other features: |
VOX. Group or private call. Backlit display. Contact list.
5 ringtones. Vibralert. Pager. Roger beep. Cloning.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | 0.14 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 50 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 1 W (ERP) |
| Modulation system: | |
| Max FM deviation (Factory set): | ±4 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2007-2011 (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (4.1 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
TSC1-AC
TSC1-DC
TSX-BP
TSX-HS1
|
Wall adapter
Dual desktop charger
NiMH battery pack. 4.8 V, 750 mAh
VOX/PTT headset
|
|
