| GENERAL |
| Type: | License-free "902-928 MHz USA" transceiver |
| Frequency range: |
TX: 906.275-923.750 MHz
RX: 161.650-163.275 / 906.275-923.750 MHz
|
| Channels / tuning steps: | Channelized (25 KHz raster) |
| Frequency stability: | ? ppm |
| Mode: |
FM with FHSS (400 ms hop rate, 50 frequencies per channel from a pool of 700)
FM no FHSS for NOAA weather channels
|
| Memory channels / management: |
1 billion "talk channels" (Hop sets)
10 NOAA weather channels
|
| Repeater shift / offset: | Simplex only |
| Power supply: | 4.5-4.8 VDC (NiMH battery pack or three LR6 / AA alkaline batteries) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | Non-removable antenna |
| Dimensions (W*H*D): | 51*121*32 mm (2*4.75*1.25") |
| Weight: | 113 g (4 oz), without batteries |
| Other features: |
VOX. Group or private call. Text messaging. Backlit display and keypad.
Contact list. Vibralert. Pager. Caller ID. 5 ringtones. Roger beep.
Cloning.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: |
FM FHSS: 0.14 uV (12 dB SINAD)
NOAA WX: 0.28 uV (12 dB SINAD)
|
| Squelch sensitivity: | |
| Selectivity: |
FM FHSS: 50 dB (Adjacent channel)
NOAA WX: 60 dB (Adjacent channel)
|
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 1 W (ERP) |
| Modulation system: | |
| Max FM deviation (Factory set): | ±4 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2007-2011 (Discontinued) |
| Additional info: |
FCC ID: O9GTSX300
|
| Related documents: |
User manual (2.8 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
TSC1-AC
TSC1-DC
TSX-BP
TSX-HS1
|
Wall adapter
Dual desktop charger
NiMH battery pack. 4.8 V, 750 mAh
VOX/PTT headset
|
|
