| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 25-1300 MHz |
| Tuning steps: | 5 / 12.5 / 25 / 50 KHz (Depending on band) |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels/memory management: |
500 regular in 10 banks @ 40 channels per second
50 monitor
10 priority
|
| Power supply: | Mains: 220-240 VAC (Fixed power cord)
or 12-14 VDC (Male barrel jack, center positive) |
| Current drain/power consumption: | Less than 12 W @ mains
Less than 400 mA @ 13.8 VDC |
| Antenna impedance/connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 232*90*210 mm (9.13*3.54*8.27") |
| Weight: | 2 Kg (4.41 lb) |
| Other features: | Attenuator. Tape out jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 225 / 226 MHz
2nd IF: 45 MHz
3rd IF: 10.7 MHz (WFM) - 455 KHz (AM/FM)
|
| Sensitivity: |
AM (20 dB S+N/N)
25-500 MHz: 2 uV
500-1000 MHz: 3 uV
1000-1300 MHz: 5 uV
FM (20 dB S+N/N)
25-500 MHz: 0.5 uV
500-1000 MHz: 1 uV
1000-1300 MHz: 2 uV
WFM
25-500 MHz: 3 uV
500-1000 MHz: 3 uV
1000-1300 MHz: 5 uV
|
| Squelch sensitivity: |
AM/FM (Threshold)
25-1000 MHz: 0.5 uV
1000-1300 MHz: 3 uV
WFM (Threshold)
25-1000 MHz: 3 uV
1000-1300 MHz: 15 uV
|
| Noise figure: | |
| Selectivity: |
AM
12 KHz (-6 dB)
24 KHz (-50 dB)
FM
20 KHz (-6 dB)
40 KHz (-50 dB)
WFM
300 KHz (-6 dB)
600 KHz (-50 dB)
|
| Image rejection: | |
| AF output power/speaker: | 1.6 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 200x-20xx (Discontinued) |
| Additional info: | |
| Related documents: | User manual (527 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
