| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-162.525 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±2.5 ppm @ -20 to +60°C (-4 to +140°F) |
| Mode: | FM / NFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
11 NOAA weather channels
Scanning
Priority function
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: Less than 410 mA
TX: Less than 1.7 A |
| Antenna impedance / connector: | 50 ohm / SMA male |
| Dimensions (W*H*D): | 61*206*33 mm (2.4*8.1*1.3"), antenna included |
| Weight: | 299 g (10.54 oz) |
| Other features: |
CTCSS/PL and DCS. IP67 waterproof. Dual PTT. USB-C charging.
Group call. Vibralert. VOX. 10 call tones. Roger beep.
NOAA weather alert. Emergency alarm. Voice guide.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: | 0.25 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 1 W at 3% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By Shenzhen Ysair Technology Co. Ltd.), 2024-202x |
| Additional info: |
FCC ID:2A3OORB48P
New price, november 2025 in the US: $61.99
|
| Related documents: |
User manual (2 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
