| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±2.5 ppm @ -25 to +60°C (-13 to +140°F) |
| Mode: | FM / NFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: 55-300 mA
TX: Less than 1.6 A |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | 63*129*39 mm (2.48*5.08*1.54") |
| Weight: | 310 g (10.93 oz), with battery and antenna |
| Other features: |
VOX. IP67 waterproof. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.2 uV (No SINAD reference) |
| Squelch sensitivity: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 1 W at 3% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Less than -36 dBm |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 202x-202x |
| Additional info: |
New price, october 2025 in the US: $72.99
|
| Related documents: | User manual (1.6 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
BL-75
|
Li-Ion battery pack. 7.4 V, 4500 mAh / 33.3 Wh
|
|
