| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±2.5 ppm @ -10 to +50°C (14 to 122°F) |
| Mode: | FM / NFM |
| Channels / memory management: |
30 GMRS
Scanning
|
| Repeater capable: | No |
| Power supply: | ? VDC |
| Current drain / power consumption: | RX: Less than 380 mA
TX: Less than 1 A |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. Micro-USB charging. VOX.
Noise canceling circuit. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Squelch sensitivity: | Less than 0.2 uV (Threshold) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2021-202x |
| Additional info: |
FCC ID: 2AN62-GMN1
New price, october 2025 in the US: $69.99 (Set of two units)
|
| Related documents: | User manual (5.3 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
