| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.275 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM |
| Channels / memory management: |
36 GMRS
10 NOAA weather channels
Scanning
|
| Repeater capable: | No |
| Power supply: | 6 VDC (NiMH battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. 5 call tones + 5 call sounds.
NOAA weather alert. Roger beep. VOX. Vibralert.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2.5 W | ? W | 500 mW |
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines, 2021-202x (Discontinued) |
| Additional info: |
FCC ID: MMAT295
New price, october 2025 in the US: $99.99 (Value pack, two units)
|
| Related documents: | User manual (1.1 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AVP1
AVP17
AVPH2
AVPH3
AVPH4
AVPH5
AVPH7
AVPH8
AVPH10
|
Over-the-ear headset kit
NiMH battery pack. 6 V, 700 mAh
Helmet headset kit
Surveillance headset
Wrap-around-the-ear headset
Behind-the-head headset
Camo headset with boom microphone
Throat microphone
Shoulder speaker-microphone
|
|
