| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.550-163.275 / 462.550-467.7125 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM / NFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
28 preset CTCSS/PL
49 user programmable
10 NOAA weather channels
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | 56*124*38 mm (2.2*4.9*1.5") |
| Weight: | 272 g (9.6 oz) |
| Other features: |
CTCSS/PL and DCS. NOAA weather alert. Dual watch.
IP67 waterproof. VOX. 10 call tones. Vibralert. SOS siren.
Roger beep. USB charging. Whisper mode. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2023-202x |
| Additional info: |
New price, october 2025 in the US: $199.99
FCC ID: MMAGXT67
|
| Related documents: | User manual (1.4 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AVP-1
AVP-H2
AVP-H3
AVP-H4
AVP-H5
AVP-H7
AVP-H8
AVP-H10
|
Over-the-ear headset with PTT
Helmet microphone kit
Surveillance headset
Ear wrap headset
Behind-the-head headset
Mossy Oak headset with boom mic
Surveillance headset
Throat mic with acoustic ear tube
|
|
