| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 76-108 / 136-174 / 400-512 MHz
|
| Tuning steps: | 2.5 / 5 / 6.25 / 10 / 12.5 / 25 KHz |
| Frequency stability: | ±2.5 ppm @ -20 to +60°C (-4 to +140°F) |
| Mode: | TX: FM / NFM
RX: FM / NFM / WFM |
| Channels / memory management: |
30 GMRS
24 DIY GMRS
128 custom
11 NOAA weather channels
Scanning and dual watch
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery) |
| Current drain / power consumption: | RX: Max 350 mA
TX: Less than 600 mA |
| Antenna impedance / connector: | 50 ohm / SMA (Female) |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. VOX. 10 selectable call alerts.
USB-C charging. Voice guide. LED flashlight. Tone call.
PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: | 0.25 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 55 dB (Adjacent channel) |
| Image rejection: | 55 dB |
| AF output power / speaker: | 1 W at 5% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM:: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2021-202x (Discontinued) |
| Additional info: |
FCC ID: 2AJGM-P11UV.
Member price, september 2025 on Amazon: $40.49 (2 pack)
|
| Related documents: | User manual (874 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
BL-11UV
|
Li-Ion battery. 7.4 V, 1500 mAh / 11.1 Wh
|
|
