| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.405 MHz |
| Channels / tuning steps: | 6 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight LR6 / AA alkaline or ten NiCd batteries)
or 12 VDC external (Male barrel jack) |
| Current drain / power consumption: | RX: 30-500 mA @ 12.5 VDC
TX: Max 1 A @ 12.5 VDC |
| Antenna impedance / connector: | - / Fixed center loaded telescopic whip
50 ohm / RCA |
| Dimensions (W*H*D): | 76*203*56 mm (3*8*2.2") |
| Weight: | ? g (? lb) |
| Other features: | Battery/power meter. Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 0.5 uV (10 dB S+N/N) |
| Squelch sensitivity: | 0.5 uV (Threshold) |
| Selectivity: | 6 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 3.5 W
Low: 1.5 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / 5-pin DIN (180°) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1986-1988 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1986 in the US: $99.95 (With XTALs for channel 14)
New price 1987 in the US: $99.95 (With XTALs for channel 14)
New price 1988 in the US: $99.95 (With XTALs for channel 14)
|
| Related documents: | |
| Known markets and approvals: |
USA
FCC ID: ?
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
