| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 8 for RX/TX and 23 for RX |
| Mode: | AM |
| Frequency control: | XTAL for 8 RX/TX channels and VFO for 23 RX channels |
| Frequency stability: | ±0.005% @ -10 to +50°C (14 to 122°F) |
| Clarifier or Delta tune: | No |
| Power supply: | Mains: 220 VAC
or 12 VDC |
| Current drain / power consumption: | RX: ? W
TX: Max 45 W |
| Antenna impedance / connector: | 35-100 ohm / SO-239 |
| Dimensions (W*H*D): | 340*140*220 mm (13.39*5.51*8.66") |
| Weight: | 7 Kg (15.43 lb) |
| Other features: | External selcall jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 1.65 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (6 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | 8 KHz (-6 dB)
20 KHz (-50 dB) |
| Image rejection: | 60 dB |
| AF output power / speaker: | 2.5 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.5 W (5 W input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -55 dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 196x-19xx (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
8 tubes.
New price 1968 in Sweden: SEK 895:-
|
| Related documents: | |
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
