| GENERAL |
| Type: | Citizen band / "Freeband" / Export transceiver and VHF scanner |
| Frequency range: |
Export mode
TX/RX: 24.715-30.105 MHz
RX only: 136-174 MHz
|
| Channels / tuning steps: |
Channel mode
480 + alphas
VFO mode
100 Hz, 1 / 5 / 10 / 100 KHz, 1 MHz
|
| Mode: | AM / FM / SSB |
| Frequency control: | PLL |
| Frequency stability: | ±5 PPM @ -20 to +55°C (-4 to +131°F) |
| Clarifier or Delta tune: | ±? KHz |
| Power supply: | 12 and 24 VDC support |
| Current drain / power consumption: | RX: 500-800 mA
TX: Max 8 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 124*39*163 mm (4.88*1.54*6.42") |
| Weight: | 668 g (1.51 lb) |
| Other features: |
ANL/NB. VOX. Echo. Noise reduction (NRC). Roger beep.
1.77" color LCD. 50 memories. Dual watch. Voltmeter.
CTCSS/PL and DCS. Repeater shift. Backlit buttons.
+10 KHz. Bluetooth. DTMF. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne (SSB)
IF: 10.695 MHz
Double conversion superheterodyne (AM/FM)
1st IF: 10.695 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 1 uV (10 dB S+N/N)
FM: 1 uV (20 dB S+N/N)
SSB: 0.25 uV (10 dB S+N/N)
|
| Squelch sensitivity: |
Adjustable: Less than 0.25 uV (Threshold)
ASQ (AM/FM): 0.5 uV (Threshold)
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Standard
AM: 4 W
FM: 4 W
SSB: 12 W (PEP)
Export mode
AM: 10 W
FM: 25 W
SSB: 25 W (PEP)
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -54 dBm |
| Microphone impedance / connector: | ? ohm / 8-pin (RJ45 modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By Qixiang Electron Science & Technology Co.Ltd.), 2025-202x |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (3 MB)
|
| Known markets and approvals: |
No known approvals for CB use
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
