| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 430-470 MHz
RX: 65-108 / 136-174 / 430-470 MHz
|
| Tuning steps: | 5 / 6.25 / 12.5 / 25 KHz |
| Frequency stability: | ? ppm |
| Mode: | TX: FM / NFM
RX: FM / NFM / WFM |
| Channels / memory management: |
99 regular
1 priority
|
| Repeater shift / offset: | Programmable |
| Power supply: | 3.7 VDC (1500 mAh standard NP60 Li-Ion battery) |
| Current drain / power consumption: | RX: 75-400 mA
TX: Max 1.4 A |
| Antenna impedance / connector: | 50 ohm / SMA-jack |
| Dimensions (W*H*D): | 47*81*23 mm (1.85*3.19*0.9") |
| Weight: | 130 gr (4.59 oz) |
| Other features: |
CTCSS/CDCSS. VOX. LED flashlight. 1750 Hz tone call.
Two-line display. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: | SoC |
| Sensitivity: | 0.2 uV (12 dB SINAD) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Low |
|---|
| 2 m: | 2 W | 1 W |
| 70 cm: | 2 W | 1 W |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2011-201x |
| Additional info: | New price 2011 in China: $43.00 |
| Related documents: |
Transceiver DSP/SDR chip: RDA1846
FM broadcast tuner chip: RDA5802E
EEPROM: 24C16
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
