| Type: | HF/VHF active antenna |
| Frequency range / band(s): | 0.04-60 MHz |
| Bandwidth: | |
| Gain: | 10 dB (Noise figure: 3.5-5 dB) |
| Beamwidth (-3 dB): | Omni |
| G/T @ 30° elevation: | - |
| Max power: | RX only! |
| Power supply: | 12.5 VDC |
| Current drain / power consumption: | Max 120 mA |
| Impedance / connector: | 50-75 ohm / ? |
| Wind area: | ? m² (? ft²) |
| Max wind resistance: | ? m/sec (? mph) |
| Turning radius: | - |
| Dimensions: | Height: 95 cm (3.12 ft) |
| Weight: | ? Kg (? lb) |
| Mast mount diameter: | ?-? mm (?-?") |
| Manufactured: | Germany, 199x-201x (Discontinued) |
| Additional info: |
Will work up to about 120 MHz with 2-3 dB lower gain.
|
| Related documents: | |
| Reviews: | Popular Communications: August 1996, page 30 |
| Options / Accessories: |
|
