Carant ACY7
SPECIFICATIONS
| Type: | Broadband UHF yagi, 7 elements |
| Frequency range / band(s): | 380-470 MHz |
| Bandwidth @ SWR: | 90 MHz @ VSWR 2:1 or less |
| Gain: | 8-11 dBi, f/b >18 dB |
| Beamwidth (-3 dB): | E-plane: ?°
H-plane: ?° |
| G/T @ 30° elevation: | - |
| Max power: | 15 W |
| Impedance / connector: | 50 ohm / FME |
| Wind area: | 0.05 m² (0.54 ft²) |
| Max wind resistance: | 30 m/sec (67 mph) |
| Turning radius: | 0.8 m (2.62 ft) |
| Dimensions: | Boom length: 755 mm (29.7")
Longest element: 400 mm (15.75") |
| Weight: | 1.03 Kg (2.27 lb) |
| Mast mount diameter: | ?-? mm (?-?") |
| Manufactured: | Hungary, 20xx-20xx |
| Additional info: | |
| Related documents: |
Product sheet (1.2 MB)
|
| Reviews: | |
| Options / Accessories: |
|
|
