| GENERAL |
| Type: | Digital audio noise filter |
| Power supply: | 12 VDC ±15% (Barrel connector, center positive) |
| Current drain / power consumption: | ? mA |
| Dimensions (W*H*D): | 260*60*250 mm (10.24*2.36*9.84") |
| Weight: | ? g (? oz) |
|
|
|
|
| AUDIO SECTION |
| Noise reduction: | More than 22 dB |
| Frequency response: |
Low-cut range
5-1280 Hz
High-cut range
500-5615 Hz
|
| Audio input: | 16 ohm or 10 Kohm (Switchable) |
| Audio output: | Headphones: 16-64 ohm (100 mW)
Speaker: 4-16 ohm (3 W @ 8 ohm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2021-202x |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Applicable radios: | Many |
