| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
Europe
25-520 / 760-1300 MHz
|
| Tuning steps: | 5 / 12.5 / 50 KHz |
| Frequency stability: | ?% |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
400 regular in 10 banks @ up to 26 channels per second
10 search pairs
10 monitor
Priority function (2 second sampling rate)
2 seconds scan resume delay (Squelch controlled)
Hyperscan
RAM storage with a 9 V battery backup
|
| Power supply: | Mains: 230 VAC (Fixed power cord)
or 13.8 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Max 18 W @ 230 VAC
Less than 725 mA @ 13.8 VDC |
| Antenna impedance / connector: | 50 ohm / BNC or detachable telescopic whip |
| Dimensions (W*H*D): | 220*76*205 mm (8.66*2.99*8.07") |
| Weight: | 2.2 Kg (4.85 lb) |
| Other features: | Sound squelch. 10 dB attenuator. Tape out. Dimmer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 607.505-611.5 MHz
2nd IF: 48.5 MHz
3rd IF: 455 KHz (AM/FM) - 10.7 MHz (WFM)
|
| Sensitivity: |
AM (20 dB S+N/N)
25-1000 MHz 2 uV
1000-1300 MHz 5 uV
FM (20 dB S+N/N)
25-1000 0.5 uV
1000-1300 MHz 3 uV
WFM (30 dB S+N/N)
25-1000 MHz 3 uV
1000-1300 MHz 10 uV
|
| Squelch sensitivity: |
Threshold (AM/FM)
25-1100 MHz: 0.5 uV
1100-1300 MHz: 3 uV
Threshold WFM
25-1100 MHz: 3 uV
1100-1300 MHz: 15 uV
|
| Noise figure: | |
| Selectivity: |
AM/FM
18 KHz (-6 dB)
30 KHz (-50 dB)
WFM
300 KHz (-6 dB)
600 KHz (-60 dB)
|
| Image rejection: | |
| AF output power / speaker: | 1.3 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By GRE), 1990-199x (Discontinued) |
| Additional info: | |
| Related documents: |
Service manual (38 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
