| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
25-54 / 108-174 / 216-225 / 406-512 / 806-824 / 849-869 / 894-960 / 1240-1300 MHz (USA)
|
| Tuning steps: | 5 / 6.25 / 7.5 / 12.5 KHz (Depending on band) |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / DV (APCO P25) |
| Channels / memory management: |
500 regular in 10 banks @ up to 60 channels per second
1 priority
NOAA weather channels
11 V-Scanner folders
Alpha tags (12 characters)
|
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | 600 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 185*55*135 mm (7.25*2.25*5.31") |
| Weight: | 790 g (1.74 lb) |
| Other features: |
Trunking: Motorola I/II/II, EDACS and LTR.
CTCSS/PL and DCS. Zeromatic (AFC). Data cloning. Attenuator. Dimmer.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 380.7275-380.86875
2nd IF: 21.4 MHz
3rd IF: 455 KHz
|
| Sensitivity: |
FM (20 dB S/N)
25-54 MHz: 0.3 uV
108-137 MHz: 0.3 uV
137-174 MHz: 0.5 uV
216-225 MHz: 0.5 uV
406-512 MHz: 0.5 uV
806-960 MHz: 0.7 uV
1240-1300 MHz: 0.7 uV
AM (20 dB S/N)
25-54 MHz: 1 uV
108-137 MHz: 1 uV
137-174 MHz: 1.5 uV
216-225 MHz: 1.5 uV
406-512 MHz: 2 uV
806-960 MHz: 2 uV
1240-1300 MHz: 3 uV
|
| Selectivity: |
AM/FM except AM 25-28 MHz
16 KHz (-6 dB)
28 KHz (-50 dB)
AM 25-28 MHz
10 KHz (-6 dB)
12 KHz (-50 dB)
|
| Image rejection: | |
| AF output power / speaker: | 1.5 W at 10% distortion / 8 ohm |
| External speaker connector: | 3.5 mm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By GRE), 2004-200x (Discontinued) |
| Additional info: |
FCC ID: ADV2000496
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
