| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
Japanese domestic market
TX: 51-54 MHz
RX: 51-54 MHz
|
| Tuning steps: | 10 / 20 KHz |
| Frequency stability: | ±? ppm |
| Mode: | FM |
| Channels / memory management: |
4 simplex
1 split
RAM storage
|
| Repeater shift / offset: | No |
| Power supply: | 13.8 VDC ±10% |
| Current drain / power consumption: | RX: 500 mA
TX: Max 2.5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 180*60*220 mm (7.09*2.36*8.66") |
| Weight: | 2.7 Kg (5.95 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.81 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.3 uV (20 dB quieting) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 12 KHz (-6 dB)
24 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 1.5 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | Variable reactance |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | 600 ohm / 6-pin (Male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-19xx (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
