| GENERAL |
| Type: | 8-bit home/training computer |
| CPU: | Rockwell 6502 @ 1 MHz |
| Operating system(s): | AIM Monitor/text editor/assembler
Optional Basic, Pascal or Forth ROMs |
| Memory: | ROM: 12 KB
RAM: 1 KB or 4 KB onboard |
| Power supply: | +5 VDC (24 VDC for printer and TTY) |
| Current drain / power consumption: | ? mA |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
|
|
|
|
| I/O |
| Keyboard: | External |
| Graphics: | 20 character LED display |
| Audio: | No |
| Storage: | Tape recorder |
| External I/O ports / connectors: |
| Tape I/O: | ? |
| RS-232C: | ? |
| Expansion ports: | Two ?-pin edge connectors |
|
| Other: | Built-in thermal printer |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1976-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | Radio & Television (Sweden): September 1980 (#9) |
| Some options / Accessories: |
?
?
?
?
?
?
?
?
|
Microflex 65 expansion chassis
8 KB static RAM
32 KB dynamic RAM
Floppy disk controller
CRT controller
General purpose I/O and timer
Asynchronous communications interface adapter
IEEE488 bus controller
|
|
