| GENERAL |
| Type: | 8-bit home computer |
| CPU: | Zilog Z80A @ 4 MHz |
| Operating system(s): | MTX BASIC (MTX-Noddy and CP/M options) |
| Memory: | ROM: 24 KB
RAM: 128 KB |
| Power supply: | 220-240 or 110-115 VAC (Separate PSU) |
| Current drain / power consumption: | ? W |
| Dimensions (W*H*D): | 486*57*203 mm (19.13*2.24*7.99") |
| Weight: | 2.6 Kg (5.73 lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated 79-key
Mechanical full-travel keys |
| Graphics: |
TMS9929A (PAL) or TMS9928A (NTSC) with 16 KB VRAM
Text: 40*24 characters
Max 256*192 pixels, 16 colors including transparent
32 sprites
|
| Audio: |
SN76489A
3 channels, 6 octaves and pink noise
|
| Storage: |
Tape recorder (2400 bd)
Optional floppy and hard drives
|
| External I/O ports / connectors: |
| Parallel port: | ?-pin (Centronics) |
| Joystick ports: | Two ? |
| Data/cartridge I/O: | ?-pin edge connector |
| Tape I/O: | ? |
| RF out: | ? |
| Video out: | ? (Composite) |
| Audio out: | ? |
| Generic I/O: | ?-pin DIL socket |
| RS-232C ports: | Two ?-pin |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1984-1985 (Discontinued) |
| Additional info: |
Introductory price 1984 in the UK: £399.00
|
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
DMX80
FDX
HDX
HRX
?
|
Printer
Floppy disk expansion unit
Hard disk expansion unit
Hi-resolution graphics adapter
80*24 column and teletext video card
|
|
