| GENERAL |
| Type: | 8-bit home computer |
| CPU: | Zilog Z80 @ 4.6 MHz |
| Operating system(s): | BBC Basic & CP/M 3.0 |
| Memory: | ROM: 256 KB
RAM: 64 KB (Expandable up to 1 MB via PC card) |
| Power supply: | 6 VDC (Four LR6 / AA batteries) or external PSU |
| Current drain / power consumption: | Max 60 mA |
| Dimensions (W*H*D): | 295*22*210 mm (11.61*0.87*8.27") |
| Weight: | 930 g (2.05 lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated |
| Graphics: | Built-in LCD: 480*64 pixels (Monochrome) and 80*8 characters (Text) |
| Audio: | One channel beeper |
| Storage: | PCMCIA (PC card) |
| External I/O ports: |
| Printer: | DB-25s / DB-25f |
| RS-232C: | DE-9p / DB-9m |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1992-1993 (Discontinued) |
| Additional info: |
Built in software: Word processor, Calculator, Diary,
Address book and Serial terminal with file transfer.
|
| Related documents: |
User manual (4.8 MB)
|
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
|
