| GENERAL |
| Type: | Amateur multimode decoder |
| CPU: | ? |
| System ROM: | ? KB |
| System RAM: | ? KB |
| Computer ports / Speed: | None |
| Power supply: | 12-16 VDC |
| Current drain / power consumption: | Less than 800 mA |
| Dimensions (W*H*D): | 229*95*337 mm (9*3.75*13.25") |
| Weight: | 2.27 Kg (5 lb) |
| Other features: |
Composite video output with 40 or 80 columns and 16 or 22 lines
selectable. Printer port for dot matrix printer.
The VF option adds Video Fax for high resolution fax images
to the printer and medium resolution images to the monitor.
|
|
|
|
|
| RADIO COMM'S SECTION |
Modes
(Depending on version): |
Version 1
Baudot (RTTY)
CW (Morse code)
SITOR A and B
NAVTEX
FAX
Version 2
FEC-A added
|
| GPS / APRS functions: | No |
| Mailbox: | No |
| Radio ports: |
TS "Minijack" (3.5 mm)
|
| Data rate over radio: | 45-75 bd (Version 1)
45-192 bd (Version 2) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1989-1998 (Discontinued) |
| Additional info: |
New price, august 1993 in the US: $429.95
New price, april 1994 in the US: $489.95
New price, october 1997 in the US: $449.95
New price, december 1998 in the US: $449.00
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
