| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
USA
TX: 143-149 MHz
RX: 143-149 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM |
| Channels / memory management: |
5 regular
XTAL controlled
|
| Repeater shift / offset: | Depending on XTALs |
| Power supply: | 11-15 VDC (12 VDC nominal) |
| Current drain / power consumption: | RX: 15-100 mA
TX: Max 620 mA |
| Antenna impedance / connector: | 50 ohm / Threaded socket |
| Dimensions (W*H*D): | 76*229*41 mm (3*9*1.62") |
| Weight: | 907 g (2 lb), with batteries |
| Other features: | S-meter. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 11.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.4 uV (20 dB quieting) |
| Selectivity: | |
| Image rejection: | 55 dB |
| AF output power / speaker: | 300 mW at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
2 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / 4-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (14 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AT-12
AT-19
AT-21
BP-2
CMA
LCC-2
LCC-3
MP-08
MP-10
PE-1
PT-3644
TN-3
TN-5
TN-50
TT-1
UAD
USA-2
|
Flexible steel whip antenna
Flexible rubber antenna
Mobile VHF/UHF antenna with gutter clip
Sealed NiCd battery pack. 12 V
Adapter for external power and antenna
Leather carrying case, heavy duty
Leather carrying case, heavy duty
External miniature microphone
Speaker-microphone
Two-tone paging encoder
Leather carrying case
CTCSS/PL encoder/decoder unit
Tone burst encoder
Two-tone squelch decoder
DTMF encoder
External antenna adapter cable
Desk charger. 120 VAC
|
|
