| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
25-1300 MHz (Cellular blocked in the US)
|
| Tuning steps: | 5 / 10 / 12.5 / 25 / 50 / 100 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
300 regular
1 priority
|
| Power supply: | 6 VDC (Four LR6 / AA batteries)
or 6 VDC external |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 64*177*44 mm (2.52*6.97*1.73") |
| Weight: | 382 g (13.47 oz), with antenna and batteries |
| Other features: | PC-programmable via RS-232C (PC version only). |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 150 mW at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1998-200x (Discontinued) |
| Additional info: | New price 2002 in the US: $249.00 |
| Related documents: |
User manual (1.4 MB)
Service manual (1.8 MB)
|
| Modifications and fixes: | |
| Reviews: | Popular Communications: April 1999, page 48 |
| Options / Accessories: |
|
