| GENERAL |
| Type: | HF/VHF receiver |
| Frequency range: |
Type 1
0.15-108 MHz
Type 2
0.15-30 / 87.6-108 MHz
Type 3
0.15-26.1 / 87.6-108 MHz
|
| Tuning steps: | LW: 3 KHz
MW: 9 or 10 KHz (Depending on ssetting)
1.6-76 MHz: 5 KHz
WFM: 50 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / SSB / WFM |
| Channels / memory management: |
40 regular in 4 pages
|
| Power supply: | 6 VDC (Four LR6 / AA batteries)
or external adapter |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / TNC
Telescopic whip and internal ferrite bar |
| Dimensions (W*H*D): | 90*182*50 mm (3.54*7.16*1.97") |
| Weight: | 650 g (1.43 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne (WFM)
IF: ? MHz
Double conversion superheterodyne (AM/SSB)
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 400 mW at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1987-19xx (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (5.2 MB)
Service manual (5.8 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AC-D4
AN-3
BP-23
DCC-120
DCC-127A
DCC-240
EBP-6
RK-69A
|
AC power adapter
VHF antenna
Rechargeable battery pack
Car battery cord
Car battery cord
Car battery cord
Battery case
Connecting cord (Miniplug to miniplug)
|
|
