| GENERAL |
| Type: | HF/VHF receiver/scanner |
| Frequency range: |
| AM: | 0.15-2.194 MHz |
| FM: | 76-108 MHz |
| AIR: | 108-137 MHz |
| PSB: | 144-174 MHz |
(Actual frequency range may differ slightly between markets)
|
| Tuning steps: | 1 / 5 / 9 / 10 / 25 / 50 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
30 or 40 regular (Depending on version)
|
| Power supply: | 6 VDC (Four LR6 / AA batteries)
or external adapter |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC
Hi-Z / TS "Minijack" (3.5 mm)
Internal ferrite bar |
| Dimensions (W*H*D): | 90*179*50 mm (3.54*7.05*1.97") |
| Weight: | 600 g (1.32 lb), with batteries and antenna |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne (WFM)
IF: 10.7 MHz
Double conversion superheterodyne (AM/FM)
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 400 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1985-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AC-D4L
AC-D4M
AN-1
AN-3
BP-23
DCC-120
DCC-127A
EBP-6
|
AC adapter
AC adapter
LW/MW/SW wide range antenna
VHF antenna
Rechargeable battery pack
Car battery cord
Car battery cord
External battery case (Four LR14 / C batteries)
|
|
