| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
Europe
68-88 / 108-136 / 138-174 / 380-512 MHz
|
| Tuning steps: | 5 / 12.5 / 25 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
200 regular in 10 banks
10 monitor
RAM storage with three button cells for backup
|
| Power supply: | 7.2-9 VDC (Six R6 / AA alkaline or NiCd batteries)
or 9 VDC external (Male barrel jack, center negative) |
| Current drain / power consumption: | 45-160 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 75*187*45 mm (2.95*7.36*1.77") |
| Weight: | 550 g (1.21 lb), with batteries |
| Other features: | Built-in charging circuit with a dedicated barrel jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM (20 dB S/N)
108-136 MHz: 2 uV
FM (20 dB S/N)
68-88 MHz: 0.6 uV
138-174 MHz: 1 uV
380-512 MHz: 1 uV
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: |
18 KHz (-6 dB)
30 KHz (-50 dB)
|
| Image rejection: | 50 dB @ 154 MHz |
| AF output power / speaker: | 300 mW at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By GRE), 1987-1987 (Discontinued) |
| Additional info: | |
| Related documents: |
AF amplifier: LM386N-1
FM-IF: TK10420
|
| Modifications and fixes: | |
| Options / Accessories: |
|
