| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
30-50 / 144-174 / 410-512 MHz (USA)
|
| Tuning steps: | ? KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
8 regular @ 10 channels per second
RAM storage with a 9 V battery backup
|
| Power supply: | Mains: 120 VAC |
| Current drain / power consumption: | ? W |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | ? mm (10.25*3.19*8.25") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
VHF: 1 uV (20 dB noise quieting)
UHF: 2 uV (20 dB noise quieting)
|
| Selectivity: | 18 KHz (-6 dB)
34 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1981-198x (Discontinued) |
| Additional info: | New price 1981 in the US: $269.95 |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
