| GENERAL |
| Type: | HF / VHF / UHF receiver/scanner |
| Frequency range: |
0.01-3000 MHz
|
| Tuning steps: | 1 / 10 / 100 Hz, 1 KHz |
| Frequency stability: | ±1.5 ppm @ -10 to +55°C (14 to 131°F) |
| Mode: | AM / FM / SSB / CW / Pulse / IQ |
| Channels / memory management: |
|
| Power supply: | 11-30 VDC
or ? VDC (Optional attachable battery) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / N-jack (Front) and SMA (Rear) |
| Dimensions (W*H*D): | 210*88*270 mm (8.27*3.46*10.63") |
| Weight: | 4 Kg (8.82 lb), without external battery option |
| Other features: |
240*64 pixels LCD. I/Q output. Attenuator. AFC. Remote control.
Tone mode, where the pitch varies according to signal strength.
RS-232C, spectrum/panoaramic display and ethernet options.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
AM (Bandwidth 6 KHz, 10 dB SINAD)
20-2700 MHz: 1 uV
2700-3000 MHz: 1.3 uV
FM (15 KHz bandwidth, 25 dB SINAD)
20-2700 MHz: 1 uV
2700-3000 MHz: 1.3 uV
|
| Selectivity: |
Available bandwidths:
150 / 300 / 600 Hz
1.5 / 2.4 / 6 / 9 / 15 / 30 / 50 / 120 / 150 KHz
|
| Image rejection: | |
| AF output power / speaker: | 500 mW at ?% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Germany, 1997-2005 (Discontinued) |
| Additional info: |
EB-110 is an EB-200 without control panel, for remote operation only
EB-150 is an EB-200 without remote control function
New price between 15.000 and 20.000 Euro + VAT depending on options.
|
| Related documents: |
User manual (2 MB)
Pocket guide (222 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
4052.9304.02
EB200-R2
EB200-R4
EB200-BP
EB200-CB
EB200-CC
EB200-CM
EB200-DS
EB200-FS
EB200-SC
EB200-SU
EB200-ZZ
HE200
|
AC power supply
RS-232C interface
LAN/Ethernet interface
Attachable battery pack
Carrying bag
Car converter
Coverage measurement software
RF spectrum Digi-Scan
Field strength measurement software
Transit case
IF panorama
Rack adapter
Active handheld directional antenna
|
|
