| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
25-550 / 800-1300 MHz
|
| Tuning steps: | 5 / 12.5 / 25 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
20 regular
|
| Power supply: | Mains: 120 VAC
or 13.8 VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | 140*76*203 mm (5.5*3*8") |
| Weight: | 1.09 Kg (2.4 lb) |
| Other features: | 24 hr clock. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
FM: 0.3 uV (No reference)
|
| Selectivity: | 15 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1983-198x (Discontinued) |
| Additional info: |
New price, august 1985 in the US: $449.00
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
