| GENERAL |
| Type: | Radar detector |
| Band(s): |
| X-band: | 10.525 GHz |
| K-band: | 24.150 GHz |
|
| Detector type(s): | |
| Antenna type: | Ridge-guide horn with dielectric focusing ring |
| RDD protection: | No |
| Laser detection: | No |
| Power supply: | 12 VDC |
| Current drain / power consumption: | Less than 250 mA |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: | City/Highway squelch. Signal meter. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ?
2nd IF: ?
|
| Sensitivity: |
X-band: -115 dBm/cm2 (±2 dB)
K band: -106 dBm/cm2 (±2 dB)
|
| Selectivity: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Reviews: | |
| Options / Accessories: |
|
