| GENERAL |
| Type: | Radar and laser detector |
| Band(s): |
| X-band: | 10.525 GHz (±50 MHz) |
| K-band: | 24.125 GHz (±125 MHz) |
| Ka-band: | 34.7 GHz (±1300 MHz) |
| Ku-band: | 13.435 GHz (±50 MHz) |
|
| Detector type(s): | |
| Antenna type: | Horn |
| RDD protection: | VG2 and Spectre I (With alert) |
| Laser detection: | 910 nm (±50 nm). 360° "LaserEye" |
| Power supply: | 12 VDC |
| Current drain / power consumption: | ? mA |
| Dimensions (W*H*D): | 78*38*124 mm (3.06*1.5*4.88") |
| Weight: | 183 g (6.45 oz) |
| Other features: |
Dot matrix display. City/Highway mode. Dimmer. Safety alert.
Strobe alert. POP alert. 8-point compass.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2006-20xx (Discontinued) |
| Additional info: | |
| Related documents: | User manual (1.6 MB) |
| Reviews: | |
| Options / Accessories: |
CLP-2B
420-026-N-001
420-030-N-001
545-139-N-001
|
Dual port power adapter
Coiled 12 VDC power cord
Straight 12 VDC power cord
Windshield mounting bracket
|
|
