| Type: | Linear regulated power supply |
| Input voltage: | 220 VAC ±10% |
| Output voltage: | 13 VDC (10-16 VDC internally adjustable) |
| Output current: | 8 A continuous (12 A peak) |
| Ripple: | 5 mVpp |
| Voltage fluctuation: | Max 1%, no load to full load |
| Efficiency: | |
| Dimensions (W*H*D): | 165*120*275 mm (6.5*4.72*10.83") |
| Weight: | 7.1 Kg (15.65 lb) |
| Manufactured: | Italy, 198x-19xx (Discontinued) |
| Additional info: |
Foldback current limiting.
|
