| GENERAL |
| Type: | Professional land mobile VHF transceiver |
| Frequency range: | 136-174 MHz (Full bandwidth, no alignment required) |
| Tuning steps: | Channelized. Programmable in 6.25 KHz increments.
Designed for 25 KHz channel spacing. |
| Frequency stability: | ±2 ppm @ -25 to +60°C (-13 to +140°F) |
| Mode: | FM |
| Channels / memory management: |
Up to 99 regular
Scanning
|
| Duplex shift / offset: | Programmable |
| Power supply: | 13.2 VDC (10.8-15.6 VDC) |
| Current drain / power consumption: |
RX: 720 mA (Squelched)
TX: 4 A @ 6 W output power
TX: 5 A @ 10 W output power
TX: 7.2 A @ 25 W output power
|
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 181*51*175 mm (7.12*2*6.89") |
| Weight: | 2.2 Kg (4.85 lb), with control head and cassette |
| Other features: |
Vacuum fluorescent display (VFD). Basic or comprehensive local or
remote controller. CTCSS/PL. Other functions depend on selected
options.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 45 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.7 uV (20 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 70 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 4 W at 4% distortion / 4-8 ohm balanced (No internal speaker) |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
6 or 25 W (Both adjustable down -10 dB from nominal)
|
| Modulation system: | |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | -37 dBm |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1986-1991 (Discontinued) |
| Additional info: |
The CQM6000 series continued for a period under the Motorola
label from 1992 onwards.
|
| Related documents: |
User manual (856 KB, in swedish)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
