| GENERAL |
| Type: | Professional land mobile transceiver |
| Frequency range: |
134-174 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
6 regular
Two XTALs per channel
|
| Duplex shift / offset: | Depending on XTALs |
| Power supply: | 9.6 VDC (NiCd battery pack)
or 12 VDC external (Male barrel jack, center negative) |
| Current drain / power consumption: | RX: Max 100 mA
TX: Max 800 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 64*172*36 mm (2.52*6.77*1.42") |
| Weight: | 570 g (1.26 lb), with battery pack |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz - Ceramic filter: Murata CFK455F
|
| Sensitivity: | 0.3 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 12 KHz (-6 dB)
24 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
3 W
|
| Modulation system: | Phase modulation |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 6-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1981-198x (Discontinued) |
| Additional info: | |
| Related documents: |
FM-IF: MC3357P
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
