Nevada TC-50DX
SPECIFICATIONS
| Type: | HF linear amplifier |
| Frequency range / band(s): | 28-30 MHz (10 m) |
| Output power: | 30 W |
| Drive power: | Max 4 W |
| Power supply: | 12-14 VDC |
| Current drain / power consumption: | Max ? A |
| Impedance / connectors: | 50 ohm / Two SO-239 |
| Dimensions (W*H*D): | 122*70*30 mm (4.8*2.76*1.18") |
| Weight: | 320 g (11.29 oz) |
| Manufactured: | England, 1987-198x (Discontinued) |
| Other: |
Harmonic filter.
New price, december 1987 in the UK: £24.95
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
|
