| GENERAL |
| Type: | HF receiver |
| Frequency range: |
10-160 m + 11 m in 7 bands (6 m/2 m/220 MHz options)
1.8-2.0 MHz (160 m)
3.5-4.0 MHz (80 m)
7.0-7.3 MHz (40 m)
14.0-14.4 MHz (20 m)
21.0-21.5 MHz (15 m)
26.5-27.5 MHz (11 m)
28.0-29.7 MHz (10 m)
|
| Tuning steps: | Continuous |
| Mode: | AM/SSB/CW |
| Channels/memory management: | No |
| Power supply: | Mains: 105-130 VAC |
| Current drain/power consumption: | Max 70 W |
| Antenna impedance/connector: | Hi-Z / random wire (50 ohms / SO-239 option) |
| Dimensions (W*H*D): | 495*286*381 mm (19.5*11.25*15") |
| Weight: | 27.2 Kg (60 lbs) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: | Double conversion superheterodyne
1st IF: 2.215 MHz
2nd IF: ? KHz |
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power/speaker: | ? W at ?% distortion / No internal speaker |
| External speaker connector: | Screw terminals, ~4 ohms |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1958-1962 (Discontinued) |
| Additional info: | |
| Related documents: | User manual (2.2 MB) |
| Modifications: | |
| Options/Accessories: |
NC-300C1
NC-300C2
NC-300C6A
NTS-2TS
XCU-300
XCU-303
|
220 MHz converter, 220-225 MHz
2 m converter, 143.5-148.5 MHz
6 m converter, 49.5-54.5 MHz
External speaker, 3.2 ohms
Crystal calibrator (100 KHz)
Crystal calibrator (100 KHz) with WWV 10 MHz RX
|
|
