| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
76.9875-88.9875 / 160.1875-172.1875 MHz
|
| Tuning steps: | Channelized
Binary programming in 12.5 KHz increments |
| Frequency stability: | ?% |
| Mode: | FM |
| Channels / memory management: |
20 regular @ 9 channels per second
RAM storage with two LR44 battery backup
|
| Power supply: | 12-15 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Less than 400 mA |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 169*54*196 mm (6.65*2.12*7.72") |
| Weight: | 1.3 Kg (2.87 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 to 0.9 uV (No SINAD reference) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1982-198x (Discontinued) |
| Additional info: |
New price 1982 in Sweden: SEK 1085:-
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
